AC Servo System 1S-series

Simplifying Motion and Safety

The 1S servo drive with motion safety functionality provides protection for the machine operators from fatal injuries and shorter machine downtimes. Integrating motion safety functions into the servo drive minimize costs, components and wiring complexity. This model supports motion safety but it is even further evolved based on the concept of the standard 1S series. With the highest-level of motion control performance and safety functionality, productivity can be further improved.

  • Descripton
  • Enquiry Now

AC Servo Drives with Built-in EtherCAT Communications and Safety Functionality



Power supply voltage Rated output Model
Single-phase/3-phase
200 VAC		 200 W R88D-1SAN02H-ECT
400 W R88D-1SAN04H-ECT
750 W R88D-1SAN08H-ECT
1.5 kW R88D-1SAN15H-ECT
3-phase 200 VAC 1 kW R88D-1SAN10H-ECT
2 kW R88D-1SAN20H-ECT
3 kW R88D-1SAN30H-ECT
3-phase 400 VAC 1 kW R88D-1SAN10F-ECT
1.5 kW R88D-1SAN15F-ECT
2 kW R88D-1SAN20F-ECT
3 kW R88D-1SAN30F-ECT



AC Servomotors with Safety Functionality

3,000-r/min Servomotors



Specifications Model
Without oil seal
Straight shaft With key and tap
Without brake 200 VAC 200 W R88M-1AM20030T R88M-1AM20030T-S2
400 W R88M-1AM40030T R88M-1AM40030T-S2
750 W R88M-1AM75030T R88M-1AM75030T-S2
1 kW R88M-1AL1K030T R88M-1AL1K030T-S2
1.5 kW R88M-1AL1K530T R88M-1AL1K530T-S2
2 kW R88M-1AL2K030T R88M-1AL2K030T-S2
2.6 kW R88M-1AL2K630T R88M-1AL2K630T-S2
400 VAC 750 W R88M-1AL75030C R88M-1AL75030C-S2
1 kW R88M-1AL1K030C R88M-1AL1K030C-S2
1.5 kW R88M-1AL1K530C R88M-1AL1K530C-S2
2 kW R88M-1AL2K030C R88M-1AL2K030C-S2
3 kW R88M-1AL3K030C R88M-1AL3K030C-S2
With brake 200 VAC 200 W R88M-1AM20030T-B R88M-1AM20030T-BS2
400 W R88M-1AM40030T-B R88M-1AM40030T-BS2
750 W R88M-1AM75030T-B R88M-1AM75030T-BS2
1 kW R88M-1AL1K030T-B R88M-1AL1K030T-BS2
1.5 kW R88M-1AL1K530T-B R88M-1AL1K530T-BS2
2 kW R88M-1AL2K030T-B R88M-1AL2K030T-BS2
2.6 kW R88M-1AL2K630T-B R88M-1AL2K630T-BS2
400 VAC 750 W R88M-1AL75030C-B R88M-1AL75030C-BS2
1 kW R88M-1AL1K030C-B R88M-1AL1K030C-BS2
1.5 kW R88M-1AL1K530C-B R88M-1AL1K530C-BS2
2 kW R88M-1AL2K030C-B R88M-1AL2K030C-BS2
3 kW R88M-1AL3K030C-B R88M-1AL3K030C-BS2





Specifications Model
With oil seal
Straight shaft With key and tap
Without brake 200 VAC 200 W R88M-1AM20030T-O R88M-1AM20030T-OS2
400 W R88M-1AM40030T-O R88M-1AM40030T-OS2
750 W R88M-1AM75030T-O R88M-1AM75030T-OS2
1 kW R88M-1AL1K030T-O R88M-1AL1K030T-OS2
1.5 kW R88M-1AL1K530T-O R88M-1AL1K530T-OS2
2 kW R88M-1AL2K030T-O R88M-1AL2K030T-OS2
2.6 kW R88M-1AL2K630T-O R88M-1AL2K630T-OS2
400 VAC 750 W R88M-1AL75030C-O R88M-1AL75030C-OS2
1 kW R88M-1AL1K030C-O R88M-1AL1K030C-OS2
1.5 kW R88M-1AL1K530C-O R88M-1AL1K530C-OS2
2 kW R88M-1AL2K030C-O R88M-1AL2K030C-OS2
3 kW R88M-1AL3K030C-O R88M-1AL3K030C-OS2
With brake 200 VAC 200 W R88M-1AM20030T-BO R88M-1AM20030T-BOS2
400 W R88M-1AM40030T-BO R88M-1AM40030T-BOS2
750 W R88M-1AM75030T-BO R88M-1AM75030T-BOS2
1 kW R88M-1AL1K030T-BO R88M-1AL1K030T-BOS2
1.5 kW R88M-1AL1K530T-BO R88M-1AL1K530T-BOS2
2 kW R88M-1AL2K030T-BO R88M-1AL2K030T-BOS2
2.6 kW R88M-1AL2K630T-BO R88M-1AL2K630T-BOS2
400 VAC 750 W R88M-1AL75030C-BO R88M-1AL75030C-BOS2
1 kW R88M-1AL1K030C-BO R88M-1AL1K030C-BOS2
1.5 kW R88M-1AL1K530C-BO R88M-1AL1K530C-BOS2
2 kW R88M-1AL2K030C-BO R88M-1AL2K030C-BOS2
3 kW R88M-1AL3K030C-BO R88M-1AL3K030C-BOS2



1,500-r/min Servomotors



Specifications Model
Without oil seal
Straight shaft With key and tap
Without brake 200 VAC 1.5 kW R88M-1AM1K515T R88M-1AM1K515T-S2
2.7 kW R88M-1AM2K715T R88M-1AM2K715T-S2
400 VAC 1.5 kW R88M-1AM1K515C R88M-1AM1K515C-S2
3 kW R88M-1AM3K015C R88M-1AM3K015C-S2
With brake 200 VAC 1.5 kW R88M-1AM1K515T-B R88M-1AM1K515T-BS2
2.7 kW R88M-1AM2K715T-B R88M-1AM2K715T-BS2
400 VAC 1.5 kW R88M-1AM1K515C-B R88M-1AM1K515C-BS2
3 kW R88M-1AM3K015C-B R88M-1AM3K015C-BS2





Specifications Model
With oil seal
Straight shaft With key and tap
Without brake 200 VAC 1.5 kW R88M-1AM1K515T-O R88M-1AM1K515T-OS2
2.7 kW R88M-1AM2K715T-O R88M-1AM2K715T-OS2
400 VAC 1.5 kW R88M-1AM1K515C-O R88M-1AM1K515C-OS2
3 kW R88M-1AM3K015C-O R88M-1AM3K015C-OS2
With brake 200 VAC 1.5 kW R88M-1AM1K515T-BO R88M-1AM1K515T-BOS2
2.7 kW R88M-1AM2K715T-BO R88M-1AM2K715T-BOS2
400 VAC 1.5 kW R88M-1AM1K515C-BO R88M-1AM1K515C-BOS2
3 kW R88M-1AM3K015C-BO R88M-1AM3K015C-BOS2



Decelerator (Backlash: 3 Arcminutes Max.)

For 3,000-r/min Servomotors



Servomotor rated output Reduction ratio Model (Straight shaft) *
200 W 1/5 R88G-HPG14A05200B[]
1/11 R88G-HPG14A11200B[]
1/21 R88G-HPG20A21200B[]
1/33 R88G-HPG20A33200B[]
1/45 R88G-HPG20A45200B[]
400 W 1/5 R88G-HPG14A05400B[]
1/11 R88G-HPG20A11400B[]
1/21 R88G-HPG20A21400B[]
1/33 R88G-HPG32A33400B[]
1/45 R88G-HPG32A45400B[]
750 W
(200 V)		 1/5 R88G-HPG20A05750B[]
1/11 R88G-HPG20A11750B[]
1/21 R88G-HPG32A21750B[]
1/33 R88G-HPG32A33750B[]
1/45 R88G-HPG32A45750B[]
750 W
(400 V)		 1/5 R88G-HPG32A052K0B[]
1/11 R88G-HPG32A112K0B[]
1/21 R88G-HPG32A211K5B[]
1/33 R88G-HPG32A33600SB[]
1 kW 1/5 R88G-HPG32A052K0B[]
1/11 R88G-HPG32A112K0B[]
1/21 R88G-HPG32A211K5B[]
1.5 kW 1/5 R88G-HPG32A052K0B[]
1/11 R88G-HPG32A112K0B[]
1/21 R88G-HPG32A211K5B[]
2 kW 1/5 R88G-HPG32A052K0B[]
1/11 R88G-HPG32A112K0B[]
2.6 kW (200 V)
3 kW (400 V)		 1/5 R88G-HPG32A053K0B[]

• Power range from 200 W to 3 kW
• 20 bit high resolution encoder
• 350% momentary maximum torque (200 V, 750 W max.)
• Battery-free absolute multi-turn encoder
• Safety over EtherCAT (FSoE)

• Servo drive for rotary motors
• Up to 3kW
• Battery-free absolute multi-turn encoder
• Advanced safety functions: STO/SS1/SS2/SOS/SLS/SLP/SDI/SBC
• Servo drive for rotary motors with one cable connection
