High-function General-purpose Inverters

Product Description

Save energy and maximize performance with versatile inverter Easy replacement The RX2 Series with the same mounting dimension as the previous model will fi t in the existing control panel or mounting location. In addition, the same setting software CX-Drive can be used for the RX2 Series. Parameter settings and programs used for the previous model can be easily converted and transferred to the RX2 Series. Note: The depth of some models may vary

<p>Built-in EMC Filter</p>

<p>Built-in noise filters corresponding to the European EMC Directive IEC61800-3 2nd Environment Category C3 and UL Power Conversion Equipment/UL61800-5-1 will save external hardware and extra cost.</p>

<p>Application customized</p>

<p>The RX2 Inverter can perform simple sequence control programmed using support software CX-Drive. Crane control, tension control, and other large-scale processes that require fast control speeds can be confi gured without a PLC, optimizing costs.</p>

<p>Easy setup and operation</p>

<p>The new full-color LCD operator, which replaced the previous 7-segment display, makes setup and operation more intuitive and easier. The parameter copy function of the operator allows you to quickly copy parameter settings to other RX2 Inverters.</p>

<p><a href="https://www.ia.omron.com/data_pdf/cat/rx2_i923-e1_1_1_csm1070917.pdf?id=3764" target="_blank">&nbsp;RX2 Series Catalog</a></p>
